Place of Origin:
China
Brand Name:
HJY
Certification:
CE, ROHS, FCC ISO9001
Model Number:
HJY-CWDM-1x2-1470-A-1-90-10-LP
|
Parameter
|
Specification
|
|
|
Channel Wavelength (nm)
|
1260 ~ 1620
|
|
|
Center wavelength Accuracy (nm)
|
±0.5
|
|
|
Channel Spacing (nm)
|
20
|
|
|
Channel Passband (@-0.5dB bandwidth (nm)
|
±7 or ±7.5nm
|
|
|
Pass Channel Insertion Loss (dB)
|
≤0.6
|
|
|
Reflection Channel Insertion Loss (dB)
|
≤0.4
|
|
|
Channel Ripple (dB)
|
<0.3
|
|
|
Isolation (dB)
|
Adjacent
|
>30
|
|
Non-adjacent
|
>40
|
|
|
Inertion Loss Temperature Sensitivity (dB/℃)
|
<0.005
|
|
|
Wavelength Temperature Shifting (nm/℃)
|
<0.002
|
|
|
Polarization Dependent Loss (dB)
|
<0.1
|
|
|
Polarization Mode Dispersion
|
<0.1
|
|
|
Directivity (dB)
|
>50
|
|
|
Return Loss (dB)
|
>45
|
|
|
Maximum Power Handling (mW)
|
300
|
|
|
Opterating Temperature (℃)
|
-25~+75
|
|
|
Storage Temperature (℃)
|
-40~85
|
|
|
Package dimension (mm)
|
Steel Tube Φ5.5x34
|
|
|
①
|
②
|
③
|
④
|
⑤
|
⑥
|
|
Wavelength
|
R- Wavelength
|
Fiber Type
|
Pigtails Diameter
|
Fiber Length
|
Connector
|
|
1270 nm
1290 nm … 1590 nm 1610 nm Or 1271 nm 1291 nm … 1591 nm 1611 nm |
A: 1270~1610
B: 1270~1450 C: 1470~1610 D: 1271~1611 E: 1271~1451 F: 1471~1611 |
1: SMF-28e
X: Others |
25:250μm
90:900μm XX: Others |
05:0.5m
10:1.0m 15:1.5m XX: Others |
00:None
FP: FC/PC FA: FC/APC SP: SC/PC SA: SC/APC LP: LC/PC LA: LC/APC ST: ST/PC XX: Others |
